Classic 125 Sport (XG12W1-IT) genuine SYM parts

Classic 125 Sport (XG12W1-IT)

Choose a section to see its exploded diagram and parts.

Click to download: official Classic 125 Sport service manual (PDF)

The Classic 125 Sport (XG12W1-IT) is powered by a 4-stroke, single cylinder, forced air cooled engine displacing 125cc, producing 8.4 kW @ 8500 rpm. Drive goes through a V-belt CVT with a centrifugal, dry type. It measures 1880mm long, 675mm wide and 1115mm tall, with a 1305mm wheelbase and a curb weight of 123kg. Top speed is 99 and above. It rides on a 110/70-12 front tire and 120/70-12 rear tire, with disc, 226mm front and disc, 220mm rear brakes.

Full specifications›

Specifications are drawn directly from the above linked service manual. Model variation specifications may vary.

Engine4-stroke, single cylinder, forced air cooled
Displacement125 cc
Bore x stroke52.4 x 57.8 mm
Compression ratio10.7±0.2:1
Max power8.4 kW @ 8500 rpm
Max torque10.3 N·m @ 6500 rpm
Fuelunleaded
Fuel tank capacity6.2 L
Ignitiontransistorized coil ignition
Starting systemelectric
TransmissionV-belt CVT
Clutchcentrifugal, dry type
Length x width x height1880 x 675 x 1115 mm
Wheelbase1305 mm
Curb weight123 kg
Top speed99 and above
Front tire110/70-12
Rear tire120/70-12
Front brakedisc, 226mm
Rear brakedisc, 220mm
Front suspensiontelescopic fork
Rear suspensiondouble

Engine

XG12W1-IT(XVB/FIDDLE ) diagram
E01XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E02XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E03XG12W1-IT(XVB/FIDDLE )
Identical to 1 diagram on other models›
No diagram
E04XG12W1-IT(XVB/FIDDLE )
Identical to 1 diagram on other models›
XG12W1-IT(XVB/FIDDLE ) diagram
E05XG12W1-IT(XVB/FIDDLE )
Identical to 1 diagram on other models›
XG12W1-IT(XVB/FIDDLE ) diagram
E06XG12W1-IT(XVB/FIDDLE )
Identical to 1 diagram on other models›
XG12W1-IT(XVB/FIDDLE ) diagram
E07XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E08XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E09XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E10XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E11XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E12XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E13XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
E14XG12W1-IT(XVB/FIDDLE )

Frame / Body

XG12W1-IT(XVB/FIDDLE ) diagram
F01XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F02XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F03XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F04XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F05XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F06XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F07XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F08XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F09XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F10XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F11XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F12XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F13XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F14XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F15XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F16XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F17XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F18XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F19XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F20XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F21XG12W1-IT(XVB/FIDDLE )
XG12W1-IT(XVB/FIDDLE ) diagram
F22XG12W1-IT(XVB/FIDDLE )

Models that share the most parts with Classic 125 Sport (XG12W1-IT)

Top five models ranked by the share of this model's part numbers they also list.

Orbit III E5 XE12W1-IT257 parts · 44.7%
Classic200i XA20W1-EU148 parts · 25.7%
SymphonyST200i XB20W1-EU130 parts · 22.6%
ECHS 125 FDA12D1CN-EU85 parts · 14.8%

Buy with confidence

How SYM parts lookup works

A few simple checks help you find the right genuine part before you order.

  1. 1

    Choose the Correct Model Code

    This can be difficult. We recommend searching by VIN, checking whether your part is available across all potentially correct model codes, and contacting us with the bike vin, engine number, model and a picture if you are unsure.

  2. 2

    Select the desired diagram

    Each model page displays all section diagrams. It also shows when a section is an exact match for a part section on another model.

  3. 3

    Select Your Parts

    Each numbered part corresponds to a number in the diagram. Parts almost always show when stock is low or out, and coloured parts display their options in a dropdown.
